Product Overview
Aluminium Chloride Anhydrous (ACA)
Aluminium Chloride Anhydrous (ACA), a compound of Aluminium and Chloride, is solid at ambient temperatures.
AL-CAT
AL-CAT+
Manufacturing Process:
ACA is manufactured by direct exothermic reaction of chlorine with pure grade Aluminium under controlled process parameters, in a closed automated system avoiding contact of product with air.
Grades:
ACA is offered in the following grades depending upon particle-size distribution of the material.
Granule Type
Powder Type
Preferred Catalyst
What Makes Our Product Unique
Aluminium Chloride Anhydrous (ACA)
High Purity (99%+)
CKKL manufactures high-purity AlCl 3 suitable for demanding industrial applications like pharmaceuticals, dyes, and petrochemicals.
Globally Certified
Our facilities follow ISO, REACH, and RoHS compliance standards to meet both domestic and international demand.
Modern Infrastructure
Our state-of-the-art plant enables efficient production with minimal environmental impact.
Reliable Supply Chain
With in-house logistics and dedicated partner networks, timely delivery is guaranteed worldwide.
Aluminium Chloride Anhydrous (ACA) Grade Specifications
| Sr No | Parameter | Unit | Powder P₁ | Powder P₂ | Granules G₁ | Granules G₂ | Granules G₃ |
|---|---|---|---|---|---|---|---|
| 1 | Appearance | – | Off white to Slight grey | Off white to Slight grey | Off white to Slight grey | Off white to Slight grey | Off white to Slight grey |
| 2 | Purity as AlCl₃ (Min.) | % | 99 | 99 | 99 | 99 | 99 |
| 3 | Water Insoluble (Max.) | PPM | 200 | 200 | 200 | 200 | 200 |
| 4 | Iron as Fe (Max.) | PPM | 30 | 30 | 20 | 20 | 20 |
| 5 | Solubility | – | Clear | Clear | Clear | Clear | |
| 6 | Free Aluminium (Max.) | PPM | 50 | 50 | 50 | 50 | 50 |
| 7 | Particle Size | MM | 0 – 1.41 | 0 – 0.85 | 1.41 – 4.76 | 4.76 – 9.50 | 1.41 – 9.5 |
Packaging Options
Aluminium Chloride Anhydrous
Bag
25 Kgs
Barrel Packing
250 Kgs HDPE
Jumbo Packaging
400 Kgs, 500 Kgs, 580 Kgs, 1000 Kgs
APPLICATION
Titanium Dioxide
(Chloride Process)
Pharmaceuticals
Agrochemicals
Pigments and Dyes
Fragrances
Catalysts
Understanding the Aluminium Chloride Manufacturing Process
Published on July 21, 2025 | By Chemfab Karaiikal Limited
Introduction
Aluminium Chloride (AlCl3) is a crucial catalyst and intermediate used in various industries including pharmaceuticals, petrochemicals, and dyes. At Chemfab Karaiikal Limited (CKKL), we follow a highly controlled and sophisticated manufacturing process to ensure product purity and operational efficiency.
How It Is Manufactured
The manufacturing of Anhydrous Aluminium Chloride at CKKL follows a meticulous process involving the chemical reaction of molten aluminium with chlorine gas inside a specially designed reactor.
Process Reaction: 2Al + 3Cl2 → 2AlCl3
The process is conducted at approximately 700°C. The exothermic reaction's heat is efficiently managed, and Aluminium Chloride vapors condense on the reactor walls, forming solid deposits that are collected and processed further.
Key Highlights of the Process
- Raw Materials: Aluminium and Chlorine
- Chlorine is bubbled through graphite sparging tubes
- Reaction occurs at ~700°C, forming AlCl3 vapors
- Condensation and collection of solid product on reactor walls
- Scrubbing system removes unreacted chlorine and gases
- Moisture-controlled silos store the final product
- Start-up takes 3–4 days, stabilization in about 3 days
- Each reactor produces ~2100 MT in its lifecycle
- Reactor runs 24/7 for operational stability
Advantages of Our Process
- Highly efficient and modular reactor setup
- Superior moisture control ensures high product purity
- Continuous production with minimal downtime
- Environmentally responsible gas scrubbing system
- Optimized for consistent and large-scale output
Conclusion
Our Aluminium Chloride manufacturing is a result of decades of engineering and process excellence. With an unwavering commitment to quality and innovation, CKKL ensures that every batch meets the strictest industrial and regulatory standards.
Why Choose CKKL?
- State-of-the-art manufacturing facility
- Strict environmental and safety compliance
- Decades of domain expertise
- Trusted partner for leading chemical consumers
Looking for a Reliable Supplier of Aluminium Chloride?
Contact us today to learn how CKKL can serve your industrial needs with the highest quality standards and seamless delivery support.
